SPERRE HV2/210 Air Compressor Parts SPERRE Main Air Compressor
HV2/210
Specifications:
| Brand | Sperre |
| Type | HV2/210 |
| Delivery Time | 1-10 Working Days According To The Parts Of Different
Specifications |
| EXW | Shanghai Of China |
| MOQ | 1 |
| Price | Negotiable |
| Payment term | T/T,L/C |
| Supply Ability | 500 Pcs Per Month |
| Packaging Detials | Wooden Package, Plywood Case, Carton, Neutral Packing |
| Place of Origin | China Original |
Air Compressor Model List:
SPERRE
SPERRE HL2/77,HL2/90,HL2/105,HL2/120,HL2/140,HL2/160
SPERRE HV1/85,HV1/120, HV1/140,HV1/156, HV140A,HV156A
SPERRE HV2/80,HV2/219,HV2/200,HV2/210,HV2/220,HV2/240,HV2/270,HV2/285,HV2/300,HV2/270A,HV2/285A,HV2/300A
Availiable Spare Part List:
1012 Crankcase .............................................. 1
1038 Crankcase hatch .................................... 1
1041 Crankcase hatch, dipstick side .............. 1
1058 Bearing cover, flywheel side .................. 1
1062 Bearing cover, oil pump side ................. 1
1076 Flywheel ................................................. 1
1103 Cylinder block ........................................ 1
1153 Frame bearing collar .............................. 3
1163 Crankshaft bearing collar ....................... 4
1171 Cooler cover, Position 1 ......................... 1
1175 Cooler cover, Position 3 ......................... 1
1231 Frame, bursting disc .............................. 1
1255 Cylinder head ......................................... 1
1297 Air filter muff ........................................... 1
1316 Valve cover, HP .................................... 2
1318 Valve cover, LP intake side ................... 1
1319 Valve cover, LP discharge side ............. 1
1330 Flywheel nut ........................................... 1
1366 No-return valve cover ............................ 1
1382 Connecting flange .................................. 1
1414 Connecting rod, LP ................................ 1
1415 Connecting rod, HP ............................... 1
1440 Inspection hatch ..................................... 1
1441 Inspection hatch, 1/2" opening............... 1
1442 Inspection hatch, M8 for gauge panel.... 1
1463 Clamp fitting, HP valve .......................... 2
1471 Clamp fitting, LP intake valve ................ 1
1472 Clamp fitting, LP discharge valve .......... 1
1516 Counterweight ........................................ 2
1530 Orifice plate ............................................ 1
2012 Crankshaft assembly ............................. 1
2998 Non-return valve .................................... 1
3245 Valve unloader, complete ...................... 1
3304 Unloader cover ....................................... 1
3311 Unloader cylinder ................................... 1
3318 Unloader piston ...................................... 1
3329 Crankshaft bearing bolt .......................... 4
3335 Crankshaft bearing nut .......................... 4
3340 Split-pin .................................................. 4
3384 Piston, LP ............................................... 1
3398 Piston, HP .............................................. 1
3446 Connecting flange, pump ....................... 1
3465 Cross bolt, LP ........................................ 1
3468 Cross bolt, HP ........................................ 1
3486 Compression/oil ring, LP ........................ 2
3505 Compression ring, HP ............................ 4
3519 Compression ring, LP ............................ 2
3533 Oil ring, HP ............................................. 1
3544 Oil ring, LP ............................................. 1
3577 Ball, lubricating oil pump ........................ 1
3583 Valve spring, lubricating oil pump .......... 1
3606 Adjusting screw, lubricating oil pump..... 1
3634 Oil level sight glass ................................ 1
3643 Manometer panel ................................... 1
3654 Cooler unit ............................................. 2
3677 Cotter pin ............................................... 1
3696 Cap nut, clamp screw ............................ 3
3697 Cap nut, oil pump .................................. 1
3700 Breather valve ....................................... 1
3713 Air filter, complete .................................. 1
3716 Flange, air outlet .................................... 1
3718 Air filter, insert ........................................ 1
3722 Oil filter ..................................................
1
3728 Oil screen ............................................... 1
3731 Oil filter holder ....................................... 1
3741 Clamp bolt, HP ...................................... 2
3742 Clamp bolt, LP ....................................... 1
3746 Dipstick .................................................. 1
3770 Manometer, cooling water/oil................. 2
3771 Manometer, LP ...................................... 1
3773 Manometer, HP ..................................... 1
3775 Spacer ................................................... 2
3781 Thermometer ......................................... 1
3783 Thermometer nipple .............................. 1
3810 Seeger ring ............................................ 4
3821 Crosshead bearing liner, LP .................. 1
3822 Crosshead bearing liner, HP ................. 1
3832 Crankshaft bearing bushes, pair ........... 2
3838 Root cock for gauge .............................. 4
3861 Shaft seal, crankshaft ............................ 1
3906 Valve gasket .......................................... 5
3909 Valve gasket .......................................... 2
3921 Frame bearing, end ............................... 2
3922 Frame bearing, centre ........................... 1
3927 Copper gasket ....................................... 13
3928 Copper gasket ....................................... 5
3929 Copper gasket ....................................... 22
3930 Copper gasket ....................................... 4
3932 Copper gasket ....................................... 4
3934 Copper gasket ....................................... 2
3946 Screw, oil pump ..................................... 4
3950 Screw, manometer panel ....................... 2
3960 Bursting disc .......................................... 1
3965 Oil pipe set ............................................. 1
3974 O-ring, air coolers .................................. 4
3979 O-ring, valve unloader ........................... 1
4033 Gasket, crankcase cover ....................... 2
4034 Gasket, cover - pump side ..................... 1
4035 Gasket, cover - flywheel side ................. 1
4053 Gasket, air outlet flange ......................... 1
4057 Gasket, HP valve cover ......................... 2
4058 Gasket, LP valve cover .......................... 2
4059 Gasket, oil pump .................................... 1
4068 Gasket ................................................... 3
4070 Gasket, cylinder head ............................ 1
4085 Gasket, air filter muff ............................. 1
4099 Gasket, cooler cover .............................. 3
4132 Lock nut ................................................. 1
